1.Technical Data
Frame | ALUMINIUM 6061, SIZE 27.5", M |
Fork | SR SUNTOUR, SF-17, With Suspension |
Color | Pearl White |
Brake Lever | WuXing, with Intergrated Sensor |
Handelbar | Aluminium, 620mm Length |
Saddle | YOSEPOWER, Brown |
Seat Post | K.W., Aluminium |
Handle Grip | Leather, Brown |
HeadSet | NECO |
BB Parts | NECO |
Brake | Tektro, M280, Disc Brake |
Brake Disc | Tektro, φ160mm |
Tire | WANDA, 27.5×1.75" |
Shifter Lever | Shimano, SL-M315 |
Freewheel | SHIMANO, 7-SPEED |
Crank | MPFWHEEL, 42T, Aluminium |
Rear Derailleur | Shimano, RD-TY200 |
Pedal | NECO |
Chain | KMC |
Motor | Shengyi, 36V 250W, Rear Drive Motor, 40N.m |
Display | Yose Power, LCD, 5 Levels |
Controller | JYT, 36V 15A, Sine Wave |
Battery | Yose Power, 36V 13Ah, 480Wh, with Sleep Function |
Front Light | 2W, 30Lux, with Reflect |
Distance | 50-100Km |
Speed | Max 25Km/h |
Net Weight | 23.5Kg |
Battery Weight | 3.2Kg |
Max Load | 125kg |
2. Warranty Listing
No. | Component | Warranty period | Warranty content |
1 | Motor | 24 Months | The motor can be replaced with a new one within 24 months. Alternatively, if damage occurs to the internal wiring, coil, or phase, if they are burned, if the magnets are demagnetized or detached, if the shaft is deformed, or if other quality issues arise that cannot be repaired, the motor can be replaced. |
2 | Motorhall, motor bearings | 24 Months | Hall sensor burnout, loud bearing noises or cracks. |
3 | Lithium battery | 18 Months | Leakage occurs or capacity less than 60 % during the first 12 months; a further 6 months applies to maintenance (except for associated battery locks, battery housing. charging sockets, battery holders and other accessories). |
4 | Frame, handlebars, rear frame, front and rear wheel hub, fork, stem, seat tube | 24 Months | Performance defects due to product reasons cannot be repaired. Welding, desoldering, breakage and distortion can be replaced. Steering handle, handlebar and deformation can be replaced. |
5 | Controller, charger, cable, inverter, power management, switch, lock, indicators, horn, brake lever, switch, handlebar guard, damper, brackets, bottom bracket, crank set, disc brakes, power OFF switch. | 24 Months | Defects in performance cannot be eliminated. Welding, desoldering, breakage and distortion can be replaced, shock absorption, oil leakage and deformation can be replaced. Damage caused by human influences such as impact and unauthorized modifications are not guaranteed. |
6 | Headlight mounting, LED bulb, | 24 Months | Welding defects, desoldering, cracking, twisting and flaking of paint are replaced |
7 | Tires, tubes, valves, spokes, | 6 Months | The inner tube is cracked or defective. Tire production damage that is not caused by wear and tear. Damage caused by human influences such as impacts and unauthorized modifications cannot be accepted. |
3. Additional Information
* The shipping takes 4-8 working days in Germany. In other countries, the shipping takes 5-10 working days.
